Product description
The MT-1200V5 is a modern veterinary anaesthesia ventilator with an LCD screen, adjustable tidal volume of 20–1,500 ml and comprehensive respiratory monitoring. It provides safety and control during anaesthesia of animals of different sizes.
**MT-1200V5** is an advanced anaesthesia ventilator ventilator created specifically for veterinary applications. The device is equipped with two bellows (0–300 ml and 50–1,600 ml), allowing it to be used with both small and large patients. The intuitive LCD display LCD display facilitates real-time control of key respiratory parameters, enabling ventilation to be precisely adapted to the patient’s needs.
The MT-1200V5 provides continuous tidal-volume adjustment over the range 20–1,500 ml/min and respiratory-rate control over the range 4–60 bpm. The built-in monitoring system tracks tidal volume (TV), respiratory rate, inspiratory-to-expiratory ratio (I:E) and peak airway pressure.
Key benefits
- Two bellows: 0–300 ml and 50–1,600 ml — for small and large animals.
- LCD display — clear, intuitive control panel.
- Tidal-volume adjustment: 20–1,500 ml/min — continuous and precise.
- Respiratory rate: 4–60 bpm — adaptable to patient size.
- Parameter monitoring: TV, I:E, respiratory rate and peak pressure.
- Stable construction and quiet operation — ideal for veterinary clinics and practices.
MT-1200V5 technical specifications
| Parameter |
Value |
| Model |
MT-1200V5 |
| Type |
Veterinary anaesthesia ventilator |
| Bellows for small animals |
0–300 ml |
| Bellows for large animals |
50–1,600 ml |
| Display |
LCD |
| Tidal-volume range (TV) |
20–1,500 ml/min (continuous adjustment) |
| Respiratory rate |
4–60 bpm |
| Monitored parameters |
TV, I:E, respiratory rate, peak pressure |
Instructions and user notes
- Select the appropriate bellows for the patient’s size (small or large).
- Set the respiratory parameters on the LCD panel before starting work.
- Monitor TV, I:E and airway pressure during the procedure.
- Calibrate the device regularly and clean the breathing-system components.
- Do not exceed the recommended pressure values in order to ensure patient safety..
